Wear Resistance Steel Stair Formwork For Construction Equipment

Name: Wear Resistance Steel Stair Formwork For Construction Equipment
Brand: Shunyao Supply Chain
Price: 80 USD

Buy cheap Wear Resistance Steel Stair Formwork For Construction Equipment product

Brand Name : Shunyao Supply Chain

Model Number : Steel stair formwork

Certification : IS0

Place of Origin : Chengdu , China

Payment Terms : T/T in advance

Delivery Time : 5-15 days

MOQ : 100 PCS

Price : $80-200

Supply Ability : Excellent

Packaging Details : Bundles

Reusability : Reusable for multiple construction cycles

Material : High-quality steel

Environmentalimpact : Eco-friendly and recyclable materials

Productname : Steel Stair Formwork

Application : Suitable for residential, commercial, and industrial stair construction

Modularity : Modular design for easy assembly and disassembly

Weightcapacity : Up to 5000 kg

Safetyfeatures : Includes safety locks and anti-slip surfaces

Surfacetreatment : Anti-rust coating

Durability : Long service life with high wear resistance

Dimensions : Customizable according to project requirements

Costefficiency : Cost-effective due to durability and reusability

Compatibility : Compatible with various concrete types

Loadbearingcapacity : Designed to support heavy loads during construction

Installationtime : Reduced installation time compared to traditional formwork

Contact Now

Technical Specification System
Main Structure: Made from 5-6mm thick high-quality Q235B steel plates stamped into shape, reinforced with #10 national standard channel steel framework, overall hot-dip galvanized treatment, with a corrosion-resistant lifespan of over 15 years.
Precision Standard: Step forming dimensional error controlled within ±1.5mm, surface flatness ≤2mm/2m, ensuring direct delivery standard for fair-faced concrete.
Load Performance: Template system lateral load-bearing capacity ≥80kN/㎡, vertical load ≥5kN/㎡, meeting high-strength concrete pouring requirements.

Core Advantages
Revolutionary Construction Breakthrough: Patented quick connection system increases formwork efficiency by 70%, reducing installation time for a single standard staircase (12 steps) to 45 minutes.
Outstanding Forming Quality: Overall stamping technology ensures absolute consistency in step dimensions, completely eliminating the cumulative dimensional deviation problems of traditional formwork.
Significant Economic Benefits: Normal usage cycles exceed 400 times, with total lifecycle cost only 18% of wooden formwork.
Safety and Intelligent Upgrade: Integrated stress monitoring sensors and intelligent early warning system, real-time monitoring of template status during pouring.

Technological Innovation
Adaptive Angle Adjustment Mechanism: Supports stepless adjustment from 15° to 50°, covering all standard staircase slopes.
Intelligent Demolding System: Built-in hydraulic push device enables zero-damage form removal.
Sealing Technology Breakthrough: Multi-layer labyrinth sealing structure completely resolves the issue of slurry leakage at step corners.
Digital Management Interface: Equipped with RFID chips and QR codes, supporting seamless integration with BIM systems.

Application Scenarios
Evacuation staircases of core tubes in super high-rise residential buildings.
Large-span curved staircases in major public buildings.
Staircases for heavy equipment in industrial plants.
Standardized modular staircase units in modular buildings.
Stair installation projects in renovation of existing buildings.

Material	Steel, stainless steel	Application	Villas, hotels, warehouses

Feature	Environmentally friendly, durable, smooth and convenient	Warranty	2 Years

Design Style	modern	After-sale Service	Online Technical Support, Onsite Installation

Project Solution Capability	3D model design, graphic design	Place of Origin	Chengdu, China

Brand Name	Shunyao Supply Chain Steel Frame	Product Name	stair railing

Color	Customer Requirements	Size	Customer s

Stair structure	Steel; Aluminum; Stainless Steel	use	Indoor, outdoor
